Emergency Rescue Fast Boat
CYG-2025
The CYG-2025 Emergency Rescue Fast Boat measures 7.5 meters in total length, 2.8 meters in beam, and 1.2 meters in draft. Constructed with a steel-aluminum composite structure for impact resistance, it accommodates 10 passengers and is equipped with a 22KW outboard motor. With a maximum speed of 45 knots and a range of 200 nautical miles at 30 knots, it combines shallow-water navigation capability with rapid rescue functions, enhancing efficient waterborne rescue operations.
Technical Specifications
Ship type parameters
Ship model
Ship classification
Emergency rescue speedboat
Ship model
CYG-2025 emergency rescue boat
Ship Name
CYG-2025 emergency rescue boat
principal dimensions
Total length (LOA)
7.5 meters (horizontal length from bow to stern)
Type width (B)
2.8 meters (maximum lateral distance between two panels)
Type Depth (D)
1.2 meters (vertical distance from keel line to upper continuous deck)
Full load draft (T)
About 0.5 meters
Weight and Capacity
Net weight (displacement)
About 2.8 tons
Load capacity (displacement)
About 1 ton (including rated passengers, fuel, fresh water, and spare parts)
Capacity (usable area)
performance metrics
speed
Rated speed of 30 knots (33.3 km/h), maximum speed of 45 knots
endurance
At an economic speed of 33.3 km/h, the cruising range is approximately 200 nautical miles.
Passenger capacity (rated)
Rated passenger capacity of 10 people
Load capacity (cargo/luggage)
Can carry 1 ton of cargo
Wind resistance and airworthiness
wind resistance rating
It can safely navigate in sea conditions with a wind speed of 10.8-13.8 meters per second and a significant wave height of 2.5 meters, under the influence of wind force 6 on the Beaufort scale
Several types of sea areas
Along the sea navigation area (≤ 20 nautical miles from shore), it can be upgraded to extend to near sea navigation area (20-50 nautical miles from shore), with airworthiness temperature ranging from -10 ℃ to 40 ℃
hull structure
Main body of the ship
High strength marine steel aluminum (underwater/main load-bearing structure)
superstructure
Ship steel (cabins/masts above deck)
Communication and Navigation
communication system
Very high frequency (VHF) wireless telephone (including DSC digital selective calling), intermediate frequency (MF) radio (long-distance communication), satellite telephone (offshore communication support)
navigation system
GPS+Beidou dual satellite navigation (positioning accuracy ≤ 10 meters), Electronic Chart Display and Information System (ECDIS)
core component
engine
engine
Standard configuration: The total power is 22 kilowatts, and dual systems or other configuration options can be selected according to the conditions of the navigation area.
propeller
propeller
Adjustable pitch propeller, made of nickel aluminum bronze alloy, resistant to cavitation and corrosion
Other parameters
Total volume of fuel tank
Total volume of fuel tank
Freshwater security
Freshwater security
Security and Authentication
Classification Society Certification
Classification Society Certification
Classification by China Classification Society (CCS), with certificates including Ship Ownership Certificate, Ship Nationality Certificate, and Safety Management Certificate (SMC)
compliance
compliance
Compliant with the Technical Regulations for Statutory Inspection of Domestic Ships (2020) and the International Convention for the Safety of Life at Sea (SOLAS) of the International Maritime Organization (IMO)
safety equipment
life-saving equipment
The entire ship is equipped with 16 life jackets
firefighting equipment
auxiliary facilities
After-sales Maintenance
maintenance cycle
maintenance cycle
The power system is maintained every 500 hours (oil filter replacement), and the hull is coated with anti fouling paint once a year to avoid rust maintenance
